Interface

1 Megabit LAN Ethernet ports

Antenna

2*2dBi Omni-directional antennas

Button

1 reset button
1 WPS button

Power

Input：100-240V—50/60Hz, 0.3A
Output：9V800mA

Indicator

1 Signal
1 WPS
1 PWR

Dimension

80 x 57 x 45mm(3.1 x 2.2 x 1.7 in.)

Wireless Standards

IEEE 802.11n/a/ac
IEEE 802.11b/g/n

Frequency

2.4GHz, 5GHz

Wireless Speed

5GHz：Up to 433Mbps
2.4GHz：Up to 300Mbps

Basic Function

Hide SSID

Wireless Security

WPA/WPA2-PSK(default)

Data Rate

802.11b: 11 Mbps
802.11g: 54 Mbps
802.11n: 300 Mbps
802.11ac：433Mbps

RSSI

2.4GHz：
11b-1M:-97dBm
11g-54M:-76dBm
11n-20M-MCS7:-74dBm
11n-40M-MCS7:-72dBm
5GHz:
11a-6M:-95dBm
11n-20M-MCS7:-74dBm
11n-40M-MCS7:-72dBm
11ac-80M-MCS9:-63dBm

Operating Mode

AP Mode and Repeater Mode

DHCP Server

Support

Wireless security protocol

Default encryption mode: Mix WPA-PSK/WPA2-PSK
Blacklist

Channel

11n：20/40MHz by default
11ac： 80MHz by default

Other

Firmware upgrade, Restore factory settings, Login password, and Reboot

Temperature

Operating Temperature: 0℃ ~ 40℃
Storage Temperature: -40℃ ~ 70℃.

Humidity

Operating Humidity:10% ~ 90% RH non-condensing
Storage Humidity: 5% ~ 90%RH non-condensing.

Certification

FCC, CE, RoHS, EAC, IC

A15 is an AC750 dual-band WiFi repeater dedicated for two-storey houses, villas, and multi-room houses with an area over 120 square meters. It offers up to 300 Mbps data rate on 11n band and 433 Mbps data rate on 11ac band. With two external omni-directional antennas, A15 can provide larger WiFi coverage, as well as extreme fast data rate, satisfying applications such as playback of 1080P HD videos, massively multiplayer online games, and high-speed download. With the upgrade Setup Wizard, it only takes you three steps to configure your repeater, which is easy to use. A15 also works better with other brands' WiFi router available on the market. For whole home WiFi coverage, A15 is your best choice.
