Standard&Protocol

IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.3af/at

LED indicator

24 * Link/Act LEDs
1 * G1 LED
1 * G2/SFP2 LED
1 * PoE-MAX LED
1 * Power LED

Interface

24 * 10/100 Mbps Base-TX RJ45 ports (Data/Power)
1 * 10/100/1000 Mbps Base-T RJ45 ports (Data)
1 * 1000 Mbps Base-X SFP port (Combo)

Forwarding Rate

6.55 Mpps

Switching Capacity

8.8 Gbps

MAC Address Table

16K

Lightning Protection

≥6KV

Input Voltage

AC: 100-240V~50/60Hz

PoE Supply

Ports 1-24 support standard IEEE802.3af/at
30W output per PoE port
230W output of the total PoE Power

Power Consumption

250W output the whole device

Dimension

440*178.8*44mm

Four Modes

Standard: Default mode of the switch. In this mode, it works as an unmanaged switch
all ports can communicate with each other separately.
Priority: In this mode, port G1 and G2/SFP2 serve as uplink ports, ports 1 – 8 serve as high priority port. All ports can communicate with each other separately.
Extend: In this mode, data rate of ports 17 - 24 reduces to 10 Mbps, the maximum transmission distance can be 250 meters, and all ports can communicate with each other.
VLAN: In this mode, ports 1 - 24 of the switch can communicate with port G1, G2/SFP2 separately, but cannot communicate with each other. You can enable this mode to reduce broadcast storm and isolate DHCP broadcast.

Environment

Operating Temperature: 0℃~45℃ (32℉~113℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Certification

CCC、FCC、CE、RoHS
